• 4-Wheel Antilock Brake Sys
• 5G Modem
• Ford App
• Hill Start Assist
• Manual Locking Hubs
• Mono Beam Coil Spring Frt Suspension W/Stab Bar
• Rear View Camera
• Remote Keyless Entry
• Sync4 W/8" Screen

• 1Touch Up/Down Dr/Pass Win
• 4.2" Cluster Display
• Air Cond, Manual Front
• Cloth Sun Visors
• Driver Seat-Manual Lumbar
• Outside Temp Display
• Particulate Air Filter
• Power Locks And Windows
• Steering:Tilt/Telescope, Cruise & Audio Controls

• Advancetrac With Rsc
• Airbags - Safety Canopy
• Belt-Minder Chime
• Driver/Passenger Air Bags
• Securilock Anti-Theft Sys
• Sos Post-Crash Alert Sys
• Tire Pressure Monit Sys

XL F-350® SRW (610A)

Ford Connectivity Package (1-year included)

CNG/Propane Gaseous Engine Prep Package

Fixed 10,000 lb. GVWR Package

Ford Security Package (1-year included)

• ELECTRONIC-LOCKING W/3.55 AXLE RATIO
• ENGINE: 6.7L HO POWER STROKE V8 TURBO DIESEL B20 -inc: manual push-button engine-exhaust braking and Operator Commanded Regeneration (OCR) 29 Gallon Fuel Tank GVWR: 11 499 lb Payload Package 3.31 Axle Ratio 190 Amp Alternator (Diesel) Dual AGM 68 AH Battery
• UPFITTER SWITCHES (6) -inc: Located in overhead console
• PLATFORM RUNNING BOARDS
• ORDER CODE 610A
• FRONT LICENSE PLATE BRACKET -inc: Standard in states requiring 2 license plates and optional to all others
• DUAL AGM 68 AH BATTERY
• WHEELS: 18 ARGENT PAINTED STEEL -inc: painted hub covers/center ornaments (STD)
• XL DRIVER ASSIST PACKAGE -inc: Pre-Collision Assist Automatic Emergency Braking (AEB) and forward collision warning Automatic High Beam
• TIRES: LT275/65RX18E BSW A/S -inc: Spare may not be the same as road tire (STD)
• LED BOX LIGHTING -inc: LED Center High-Mounted Stop Lamp (CHMSL)
• ENGINE BLOCK HEATER -inc: grille cover
• 250 AMP ALTERNATOR
• SNOW PLOW/CAMPER PACKAGE -inc: computer selected springs for snowplow application and slide-in camper certification Note 1: Salesperson's source book or Ford RV trailer towing guide should be consulted for specific trailer towing or camper limits and corresponding required equipment axle ratios and model availability Restrictions apply; see supplemental reference or body builders layout book for details Expect firmer ride when vehicle is not equipped w/snowplow and/or camper Note 2: May result in deterioration of ride quality when vehicle is not equipped w/snowplow and/or camper Rear Stabilizer Bar & Auxiliary Springs
• TRAILER BRAKE CONTROLLER -inc: smart trailer tow connector
• 190 AMP ALTERNATOR
• Locking/Limited Slip Differential
• Four Wheel Drive
• Tow Hitch
• Power Steering
• ABS
• 4-Wheel Disc Brakes
• Brake Assist
• Steel Wheels
• Tires - Front All-Season
• Tires - Rear All-Season
• Conventional Spare Tire
• Tow Hooks
• Heated Mirrors
• Power Mirror(s)
• Integrated Turn Signal Mirrors
• Intermittent Wipers
• Variable Speed Intermittent Wipers
• Power Door Locks
• Daytime Running Lights
• Automatic Headlights
• AM/FM Stereo
• MP3 Capability
• MP3 Capability
• Steering Wheel Audio Controls
• Bluetooth® Connection
• Telematics
• Auxiliary Audio Input
• Smart Device Integration
• Requires Subscription
• Bluetooth® Connection
• Adjustable Steering Wheel
• Trip Computer
• Keyless Entry
• Power Door Locks
• Cruise Control
• A/C
• Vinyl Seats
• Split Bench Seat
• Driver Adjustable Lumbar
• Passenger Vanity Mirror
• Smart Device Integration
• Requires Subscription
• Smart Device Integration
• WiFi Hotspot
• Power Windows
• Power Door Locks
• Trip Computer
• Security System
• Immobilizer
• Traction Control
• Stability Control
• Traction Control
• Front Side Air Bag
• Telematics
• Requires Subscription
• Tire Pressure Monitor
• Driver Air Bag
• Passenger Air Bag
• Passenger Air Bag On/Off Switch
• Front Head Air Bag
• Back-Up Camera

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 750
• Cold Cranking Amps @ 0° F (2nd): 750
• Maximum Alternator Capacity (amps): 190 & 0
• Maximum Alternator Capacity (amps): 160
• Weight Information
• Base Curb Weight (lbs): 7044
• Base Curb Weight (lbs): 6228
• Gross Axle Wt Rating - Front (lbs): 4400
• Gross Axle Wt Rating - Rear (lbs): 6780
• Curb Weight - Front (lbs): 3690
• Curb Weight - Rear (lbs): 2538
• Gross Vehicle Weight Rating Cap (lbs): 10900
• Gross Combined Wt Rating (lbs): 21000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 14300
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1430
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 14100
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 3525
• Maximum Trailering Capacity (lbs): 14300
• Suspension
• Suspension Type - Front: Other
• Suspension Type - Rear: Leaf
• Spring Capacity - Front (lbs): 4400
• Spring Capacity - Rear (lbs): 6780
• Axle Type - Front: Non-Independent
• Axle Type - Rear: Rigid Axle
• Axle Capacity - Front (lbs): 6000
• Axle Capacity - Rear (lbs): 7280
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.73
• Brakes
• Brake Type: 4-Wheel Disc
• Brake ABS System: 4-Wheel
• Brake ABS System (Second Line): 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 14.3
• Rear Brake Rotor Diam x Thickness (in): 14.3
• Tires
• Front Tire Order Code: TCH
• Rear Tire Order Code: TCH
• Front Tire Size: LT275/65SR18
• Rear Tire Size: LT275/65SR18
• Spare Tire Size: Full-Size
• Front Tire Capacity (lbs): 6830
• Rear Tire Capacity (lbs): 6830
• Revolutions/Mile @ 45 mph - Front: 646
• Revolutions/Mile @ 45 mph - Rear: 646
• Wheels
• Front Wheel Size (in): 18 X 8
• Rear Wheel Size (in): 18 X 8
• Spare Wheel Size (in): Full-Size
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Re-Circulating Ball
• Turning Diameter - Curb to Curb (ft): 47.6
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 29
• Fuel Tank Capacity, Approx (gal): 34
• Exterior Dimensions
• Wheelbase (in): 142
• Length, Overall (in): 231.8
• Width, Max w/o mirrors (in): 80
• Height, Overall (in): 81.2
• Overhang, Front (in): 38.2
• Cab to Axle (in): 56.1
• Ground to Top of Load Floor (in): 37.4
• Ground Clearance, Front (in): 8.5
• Ground Clearance, Rear (in): 8.5
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 98.1
• Cargo Box Width @ Top, Rear (in): 66.9
• Cargo Box Width @ Floor (in): 66.9
• Cargo Box Width @ Wheelhousings (in): 50.5
• Cargo Box (Area) Height (in): 21.1
• Tailgate Width (in): 60.5
• Cargo Volume (ft³): 78.5
• Interior Dimensions
• Passenger Capacity: 3
• Front Head Room (in): 40.8
• Front Leg Room (in): 43.9
• Front Shoulder Room (in): 66.7
• Front Hip Room (in): 62.5
• Summary
• Vehicle Name: Ford Super Duty F-350 SRW
• Body Style: SD Regular Cab
• Body Code: T
